Merrithew Pilates REHAB V2 MAX PLUS Reformer with Deluxe Bundle (ST01085)

Merrithew Split-Pedal Stability Chair - Fitness Outlet

Vendor: Merrithew Stott Pilates

Merrithew REHAB V2 MAX PLUS Reformer with Deluxe Bundle

$8,599.00

Sku: ST-01085

Product variants

Estimated Delivery in 6–10 Days

Share:

Share

Pairs well with

Description

STOTT PILATES® Rehab V2 Max Plus™ Reformer with Deluxe Bundle

The Rehab V2 Max Plus™ Reformer with Deluxe Bundle is MERRITHEW’s most versatile rehabilitation-focused Reformer. Ideal for physical therapy clinics, rehab centers, and facilities serving aging or mobility-limited populations, this elevated unit combines the accessibility of a raised carriage with the advanced functionality of a vertical frame for Cadillac-style movement patterns.

With variable angles of resistance and a full complement of spring and pulley options, this Reformer empowers therapists and instructors to create safe, effective programming for recovery, injury prevention, and full-body strength.

Key Benefits:

Raised Reformer Height (22.5") – Allows for easier access and safer transitions for clients with limited mobility
Integrated Vertical Frame – Offers a wide range of Cadillac-style exercises with adjustable pulley angles for tailored support and challenge
Deluxe Bundle Value – Includes Mat Converter, Reformer Box with footstrap, Padded Platform Extender, and Maple Roll-Up Pole — a $900+ value, included for just $300 more

What’s Included:

Rehab V2 Max Plus™ Reformer
Vertical Frame with Cadillac Components:
- 2 Push-Thru Springs
- 2 Roll-Down Springs with Maple Roll-Down Bar
- 2 Arm Springs with Foam Grip Handles
- 2 Leg Springs with Padded Long Spine Straps
- 2 Extension Straps
- 2 Travelling Spring Hooks and 2 Travelling Pulleys
- Safety Chain
Mat Converter – Converts the Reformer to a raised Matwork/Cadillac surface
Reformer Box with Footstrap
Padded Platform Extender
Maple Roll-Up Pole
High Precision Spring Package (5 springs: 3 × 100%, 1 × 50%, 1 × 25%)
Neoprene Spring Covers – For quiet, controlled movement
Patented Retractable Rope System – Easily adjust rope lengths mid-session
High-Traction Reformer Feet
Carriage Stopper + Easy-Roll Transport Wheels
Soft Reformer Loops
Owner’s Manual
Choice of 10 standard or 75 custom upholstery colors – Specify at checkout

Performance Features:

Patented Rolling Mechanism + C-Channel Aluminum Rails – Delivers a smooth, friction-free carriage glide
Robust Comfort Footbar – Easier on hands and sensitive feet; adjustable to 4 positions
Adjustability for All Needs:
- 3 Gearbar Positions (Upgradeable to 6*)
- 6 Carriage Stopper Positions
- 3 Headrest Positions
- Pommel-Style Removable Shoulder Rests
Enhanced Springs – Built for high-impact use with Jumpboards and Cardio-Tramp® Rebounders
1" Thick Standing Platform – For added stability and proprioceptive feedback
Minimal Assembly Required

Customize your Reformer

Need extra length?
Add 6 in (15 cm) to the length of your Reformer with an extension upgrade.

Need more precision?

Double your number of Gearbar positions with the High-Precision Gearbar upgrade. Available on this product at time of purchase. Note, upgrade must be added at the same time you purchase your new Reformer and installed by our factory. The High-Precision Gearbar cannot be retrofitted to existing Reformers.

Specifications

Dimensions · Reformer
Width	30 in	76.2 cm
Length	97 in	247 cm
Weight	185 lbs	83.9 kg

Dimensions · Reformer carriage
Width	24 in	61 cm
Length	38.5 in	98 cm
Height from floor	22.5 in	57.2 cm

Dimensions · Vertical Frame
Width	30.5 in	77.5 cm
Height	79.5 in	202 cm
Minimum ceiling height	90 in	228.6 cm
Weight	41.5 lbs	18.2 kg

Weight capacity: 350 lbs (159 kg)

Specifications

Specifications data

Reformer:

30 in W × 97 in L (76.2 cm × 247 cm)

Weight: 185 lbs (84 kg)

Carriage: 24 in W × 38.5 in L × 22.5 in H (61 cm × 98 cm × 57.2 cm)

Vertical Frame:

30.5 in W × 79.5 in H (77.5 cm × 202 cm)

Weight: 41.5 lbs (18.2 kg)

Minimum Ceiling Height: 90 in (228.6 cm)

User Weight Capacity: 350 lbs (159 kg)

Warranty

Warranty data

PROFESSIONAL · REHAB REFORMER WARRANTY

(SPX® Max, V2 Max™, SPX® Max Plus™, V2 Max Plus™, Rehab V2 Max Plus™)

Limited Lifetime Warranty

• Aluminum Rails
• Frame Components & Welding
• Footbar Mechanisms (excluding Comfort Footbar)

ALL REFORMER MODELS
90 Days – Fabric & Upholstery

(Subject to standard warranty conditions)

1 Year – Wear & Tear Items

• Ropes
• Rollers
• Straps
• Spring Clips
• Plastic Pulley Bar Receptacle Sleeves
• Comfort Footbar Covering
• Plastic Reformer Feet
• Spring O-Rings
• Molded Spring Holder
• Spring Covers

2 Years – All Other Reformer Components

FAQs

Frequently asked question

Is the Merrithew REHAB V2 MAX PLUS Reformer worth the investment for a small physical therapy clinic?

Absolutely. The REHAB V2 Max Plus is built for clinical use, combining a raised carriage for easy patient access with Cadillac-style vertical frame functionality. This eliminates the need for multiple pieces of equipment, saving space and cost. Its durability, versatility across mobility levels, and professional-grade construction make it a smart long-term investment for clinics serving rehabilitation or aging populations.

What does the Deluxe Bundle include, and does it add enough value to justify the package price?

The Deluxe Bundle adds a curated set of accessories designed to expand treatment options right out of the box. These typically include props and attachments that support a wide range of rehab and Pilates exercises. Rather than sourcing accessories separately, the bundle provides immediate clinical readiness and better overall value compared to purchasing items individually.

Who is the REHAB V2 MAX PLUS Reformer designed for?

This Reformer is designed for physical therapists, rehab specialists, and fitness professionals working with clients who have mobility limitations, injuries, or age-related movement challenges. Its elevated carriage height and vertical frame make it especially accessible for individuals who struggle with getting up from a low surface, making it ideal for clinical and senior-focused facilities.

What makes this Reformer different from a standard Pilates Reformer?

Unlike standard Reformers, the REHAB V2 Max Plus features a raised carriage height for easier on and off access, a vertical frame for Cadillac-style exercises, and variable resistance angles. These features support a broader range of therapeutic movement patterns, making it far more suitable for rehabilitation settings than a traditional floor-level Reformer.

How much space do I need to accommodate the REHAB V2 MAX PLUS Reformer?

Due to its elevated frame and vertical structure, this unit requires more ceiling clearance and floor space than a standard Reformer. We recommend reviewing the official product dimensions before purchase and ensuring adequate room for safe patient movement around all sides of the equipment. Consulting a Merrithew representative can help you plan your space layout effectively.

Can the REHAB V2 MAX PLUS be used for general Pilates classes, or is it strictly for rehabilitation?

While designed with rehabilitation in mind, this Reformer is fully capable of supporting general Pilates programming. Its advanced functionality, spring resistance system, and Cadillac attachments make it versatile enough for wellness, athletic conditioning, and traditional Pilates instruction. It's an excellent choice for facilities that want one piece of equipment to serve both rehab and fitness clients.
